Technical

Network Bandwidth	Dante® Network 1000M
Audio Latency	Configurable Dante® device latency; supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller
Audio Format	Dante®/AES67 digital audio in/out, PCM 8CH 44.1kHz to 96kHz, 16/24-bit
Sampling Rate Conversion	Up to 96kHz
Transmission Distance	328ft / 100m via CAT6/6A/7 cable
ESD Protection	IEC 61000-4-2: +/-8kV air-gap discharge and +/-4kV contact discharge

Connections

Network A	1x DANTE PRIMARY, RJ45 locking connector, PoE: PoE IEEE802.3af Class 0; Dante®/AES67 digital audio in/out, PCM 2CH 44.1kHz to 96kHz, 16/24-bit, Web GUI and TCP/IP 1x DANTE SECONDARY, RJ45 locking connector, PoE: PoE IEEE802.3af Class 0; Dante®/AES67 digital audio in/out, PCM 2CH 44.1kHz to 96kHz, 16/24-bit
Network B	1x DANTE PRIMARY, RJ45 locking connector; Dante®/AES67 digital audio in/out, PCM 2CH 44.1kHz to 96kHz, 16/24-bit, Web GUI and TCP/IP 1x DANTE SECONDARY, RJ45 locking connector; Dante®/AES67 digital audio in/out, PCM 2CH 44.1kHz to 96kHz, 16/24-bit
Power Input	1x DC 12V IN, DC locking power jack, max 1A

Mechanical

Housing	Metal enclosure
Color	Turtle Aqua
Dimensions	210mm (W) x 150mm (D) x 44mm (H)
Weight	974g
Power Supply	12V/1A locking power supply; PoE+/PD, Class 4 IEEE 802.3at
Power Consumption	6.6W max, tested with 1Hz sine wave
Operating Temperature	0°C to 40°C / 32°F to 104°F
Storage Temperature	-20°C to 60°C / -4°F to 140°F
Operating Humidity	20% to 80% relative humidity, non-condensing
Storage Humidity	10% to 90% relative humidity, non-condensing
