Technical

Input1-channel balanced XLR analog audio
OutputDante® 2CH digital audio
Control MethodDante® Controller
Network Bandwidth100M
Audio LatencyConfigurable Dante® device latency; supports 2, 3, 4, 5 or 10ms configurable using Dante® Controller
Audio Formats
  • MIC IN: balanced XLR analog audio input, max input level +24dBu
  • Dante® OUT: digital audio output, PCM 2CH 44.1kHz to 96kHz, 16/24-bit
XLR Analog Audio In
  • Input impedance: 20k Ohm balanced, 10k Ohm unbalanced
  • Line input level (maximum): +24dBu (12.28Vrms) @ balanced audio; +18dBu (6.15Vrms) @ unbalanced audio
  • Frequency response: 20Hz to 20kHz (-/+0.5dB)
  • Dynamic range: >110dB @ 0dBu, 1kHz, A-weighted
  • Audio S/N ratio: >105dB @ 0dBu, 1kHz, A-weighted
  • Audio THD+N: <0.01% @ +4dBu, 1kHz
  • Audio output sync delay: <1ms
Transmission Distance328ft / 100m via CAT6/6A/7 cable
ESD ProtectionIEC 61000-4-2: +/-8kV air-gap discharge and +/-4kV contact discharge

Connections

Input Port1x XLR IN, XLR female plug
Output Ports
  • 1x DANTE PRIMARY, RJ45 locking connector, PoE/PD, Class 0 IEEE 802.3at; Dante/AES67 digital audio in/out, PCM 2CH 44.1kHz to 96kHz, 16/24-bit, Web GUI and TCP/IP
  • 1x DANTE SECONDARY, RJ45 locking connector, PoE/PD, Class 0 IEEE 802.3af; Dante/AES67 digital audio in/out, PCM 2CH 44.1kHz to 96kHz, 16/24-bit

Mechanical

HousingAluminum
ColorGray
Dimensions60mm (W) x 45mm (D) x 145mm (H)
Weight295g
Power SupplyPoE
Power Consumption1.55W max
Operating Temperature32°F to 104°F / 0°C to 40°C
Storage Temperature-4°F to 140°F / -20°C to 60°C
Operating Humidity20% to 80% relative humidity, non-condensing
Storage Humidity10% to 90% relative humidity, non-condensing
