Technical

Audio Channels	2CH XLR and Dante®
Input	2x XLR audio input with 5-level sensitivity/gain control
Phantom Power	48V phantom power
DSP Processing	Built-in DSP processing, including expander and 8-band parametric EQ
Sample Rates	44.1kHz, 48kHz and 96kHz at 24-bit
Audio Latency	1, 2 or 5ms configurable latency using Dante® Controller
Audio Transport	AES67 RTP audio transport supported

Connections

Audio Input	2x XLR audio inputs
Network Audio	Dante® network audio with AES67 RTP support
Power Input	PoE, Class 0 IEEE 802.3af, or local 12V DC power supply

Mechanical

Form Factor	Standard 1-Gang EU Decora design
Color	White/Black
Power Supply	PoE, Class 0 IEEE 802.3af, or local 12V DC power supply
